Topographic Slopes of Mars 2020 Landing Site Jezero West

Primary Authors

Robin L. Fergason

Originators

R.L. Fergason, T.M. Hare, R.L. Kirk, S. Piqueux, D.M. Galuzska, M.P. Golombek, R.E. Otero, B.L. Redding

Publisher

USGS Astrogeology Science Center

Publication Date

2017-03-20

Abstract

This product represents adirectional topographic slopes over 20 meter horizontal baselines within part of a candidate landing site for the Mars2020 mission. The slope map was derived from a CTX-based digital terrain model. This slope map was produced as part of an effort to characterize terrain within candidate landing ellipses for the Mars2020 mission and to aid entry, descent, and landing simulations for the mission. The parent DTM was constructed from a pair of CTX images using the stereo photogrammetry software SOCET SET® (BAE Systems). The DTM from which this product was derived is available under the "Related Products" section on the right of this page. Preferred Citation: R.L. Fergason, T.M. Hare, R.L. Kirk, S. Piqueux, D.M. Galuzska, M.P. Golombek, R.E. Otero, and B.L. Redding, 2017, "Mars 2020 Landing Site Evaluation: Slope and Physical Property Assessment," 48th Lunar and Planetary Science Conference, held 20-24 March 2017, at The Woodlands, Texas. LPI Contribution No. 1964, id.2163. Reference: R.L. Fergason, R.L. Kirk, G. Cushing, D.M. Galuszka, M.P. Golombek, T.M. Hare, E. Howington-Kraus, D.M. Kipp, B.L. Redding, 2016, "Analysis of Local Slopes at the InSight Landing Site on Mars," Space Sci. Rev., 1572-9672, doi:10.1007/s11214-016-0292-x.

Purpose

This slope map was produced as part of an effort to characterize terrain within candidate landing ellipses for the Mars2020 mission and to aid entry, descent, and landing simulations for the mission.

Contact and Distribution

Format

Digital Elevation Model, Landing Site Map, Raster Data

Access Constraints

Public Domain

Access Scope

Use Constraints

Please Cite Authors

Edition

1

Supplemental Information

https://dx.doi.org/10.1007/s11214-016-0292-x

Native Data Set Environment

ISIS v3

Astrogeology Theme

Landing sites, Photogrammetry, Topography

Mission Names

Mars 2020, Mars Reconnaissance Orbiter

Instrument Names

CTX

Online Package Link

https://astrogeology.usgs.gov/search/map/topographic_slopes_of_mars_2020_landing_site_jezero_west

External File Size

42 MB

Online File Link

https://planetarymaps.usgs.gov/mosaic/mars2020_landing_site_dtm/J03_045994_1986_J03_046060_1986_20m_slope_20m.tif

Contact Address

2255 N. Gemini Drive

Contact City

Flagstaff

Contact State

AZ

Contact Postal Code

86001

Contact Email

astroweb@usgs.gov

Currentness Reference

Publication date

Progress

Complete

Update Frequency

None planned

Process Description

See Fergason et al. (2016) for a detailed processing description. The 20 meter baseline adirectional slope raster is derived from a 20 m/pixel CTX DTM. The Python script used to generate the slope raster is available here: https://github.com/USGS-Astrogeology/GDAL scripts/blob/master/gdal_baseline_slope/gdal_baseline_slope.py

Source Title

CTX

Source Online Linkage

http://pds-imaging.jpl.nasa.gov/volumes/mro.html

Source PDS Archive

Mars Reconnaissance Orbiter

Horizontal Positional Accuracy Report

Accurate to Control Net

Vertical Positional Accuracy Report

Accurate to Control Net

Geospatial Information

Target

Mars

System

Mars

Minimum Latitude

17.5357701886749

Maximum Latitude

19.319900654779396

Minimum Longitude

77.08259594661347

Maximum Longitude

77.7959073249433

Direct Spatial Reference Method

Raster

Object Type

Grid Cell

Raster Row Count (lines)

5235

Raster Column Count (samples)

2093

Bit Type (8, 16, 32)

32

Quad Name

MC-13

Radius A

3396190

Radius C

3396190

Bands

1

Pixel Resolution (meters/pixel)

20.201297749849

Scale (pixels/degree)

2934.202458540035

Map Projection Name

Equirectangular

Latitude Type

Planetocentric

Longitude Direction

Positive East

Longitude Domain

-180 to 180
