Level0 HiRISE¶
Acquiring Data¶
Data Products¶
EDR and RDR - Use EDR for ISIS.
The HiRISE team produces two types of PDS data products:
-
Experiment Data Record (EDR).
HiRISE EDRs contain the data collected by 1 channel (of 28) on the instrument and transmitted back to earth. For one HiRISE observation, there are up to 28 EDR files to download for processing. -
Reduced Data Record (RDR).
HiRISE RDRs contain a radiometrically calibrated, map projected, mosaic of multiple channels from a single observation. These products are stored in JPEG 2000 format.
One HiRISE EDR Observation contains up to 28 images
To make full use of a HiRISE Observation, the processing steps must be run on each of the images in the observation: RED0-9, IR10-11, BG (Blue-Green) 12-13, each with its own channel 0 and 1.
Those interested in a particular wavelength of light might examine a subset of filters.
Their wavelengths are RED: 570-830nm, BG: <580nm, IR: >790nm
Search Tools¶
Search for HiRISE images on PDS Image Atlas III
or PDS Image Atlas IV (Beta).
Data products from other instruments and spacecraft are also available here.
Helpful Search Filters
These filters may help narrow your search on the PDS Image Atlas:
- Instrument (HiRISE)
- Target (Mars)
- Product Type (EDR, if processing in ISIS)
- Filter (Red, IR, or BG)
- Latitude/Longitude
- Orbit Number
- Mission Phase
Maps¶
The HiRISE Browse Map (UofA)
can be used to find images visually, or by proximity to named geologic features.
To show HiRISE images only, check HiRISE Observations and uncheck everything else under Show below the map.
The Find search box under the map is for named geologic features (like 'Alba Mons'), not filenames of images.
The map must be zoomed in to show HiRISE observation footprints.
The PDS Image Atlas IV (Beta) has a map which can be searched by drawing a box around an area of interest.
Data Volumes¶
Browse for images manually on the HiRISE Online Data Volume (UofA).
HiRISE File Naming Conventions
Understanding the filename can be helpful when searching for data and managing files. The PDS naming convention for channel EDRs is
AAA_BBBBBB_CCCC_DDD_E.IMG
Where:
- AAA: mission phase
- AEB Aerobraking
- TRA Transition
- PSP Primary Science Phase
- REL Relay
- Exx Extended missions (if needed)
- BBBBBB: Orbit Number
- CCCC: Target Code
- The latitudinal position of the center of the planned observation relative to the start of the orbit. The first three digits are whole degrees, the fourth digit the fractional degrees rounded to 0.5 degrees. (example Mars target codes on a descending orbit: 0900 for 90.0° or south-pole, 1800 for 180.0° or equator, 2700 for 270.0° or north-pole)
- DDD: Filter/CCD Identifier (RED0-RED9, IR10, IR11, BG12, BG13)
- E - Channel Number (0 or 1)
For example, PSP_002733_1880_RED5_0.IMG is an image centered at 188.0° latitudinal degrees from the start of the orbit around Mars, collected by channel 0 of CCD 5, red filter, during orbit 2733 of the primary science phase. See the Software Interface Specification for HiRISE Experiment Data Record Products (PDF) for additional details.
Similarly, the PDS naming convention for RDR mosaicked observation products is
AAA_BBBBBB_CCCC.IMG
Browsing by Volume - File Structure
PDS¶
The PDS folder has subfolders by product type. For processing in ISIS, look in the EDR Directory.
> EDR - Product Type¶
The EDR folder has subfolders by mission phase. For processing in ISIS, the most useful are PSP (Primary Science Phase) and ESP (Extended Science Phase).
> > PSP - Mission Phase¶
The PSP folder has subfolders containing 100 orbits each, named as ORB_[start orbit #]_[end orbit #]. Lower orbit numbers are earlier in the mission, and higher orbit numbers are later.
> > > ORB_002700_002799 - Orbit¶
Each Orbit folder has a subfolder for each observation, labeled Mission_Orbit_TargetCode (PSP_002733_1880). See above naming conventions for an explanation of the target code.
> > > > PSP_002733_1880 - Observation¶
Each Observation folder has a file for each sub-image in the observation, suffixed by filter and channel (RED4_0).
> > > > > PSP_002733_1880_RED4_0.IMG - .IMG File¶
PDS
↳ EDR .......................................... (Product Type)
↳ PSP ...................................... (Mission Phase)
↳ ORB_002700_002799 .................... (Orbit Number)
↳ PSP_002733_1880 .................. (Observation)
↳ PSP_002733_1880_RED4_0.IMG ... (File)
Ingestion¶
EDR Format and Labels¶
HiRISE Data
First 4000 lines of an 80000 line EDR.
Orbit 2733.
To work with HiRISE data in ISIS, the HiRISE EDR file must be converted to an ISIS cube so ISIS programs can read and process the data.
EDR files have the .IMG file extension. They
have image data and text describing the image data/the
state of the instrument at the time the image was taken. The text is in
the PDS Standard format at the beginning of the file.
Only the information needed by other Isis programs is transferred from
the PDS label to the ISIS cube label.
Sample PDS Label from PSP_002733_1880_RED4_0.IMG
PDS_VERSION_ID = PDS3
/* File structure: */
/* This file contains an unstructured byte stream. */
/* The UNDEFINED RECORD_TYPE is used to meet PDS standards requirements. */
/* A label "record" is actually a single byte. */
RECORD_TYPE = UNDEFINED
/* Locations of Data Objects in the file. */
/* >>> CAUTION <<< The first byte is location 1 (not 0)! */
LABEL_RECORDS = 32768 <BYTES>
^SCIENCE_CHANNEL_TABLE = 32769 <BYTES>
^LOOKUP_TABLE = 33569 <BYTES>
^CPMM_ENGINEERING_TABLE = 49953 <BYTES>
^CALIBRATION_LINE_PREFIX_TABLE = 50013 <BYTES>
^CALIBRATION_LINE_SUFFIX_TABLE = 50013 <BYTES>
^CALIBRATION_IMAGE = 50013 <BYTES>
^LINE_PREFIX_TABLE = 227757 <BYTES>
^LINE_SUFFIX_TABLE = 227757 <BYTES>
^IMAGE = 227757 <BYTES>
^GAP_TABLE = 84867757 <BYTES>
/* Identification information. */
DATA_SET_ID = MRO-M-HIRISE-2-EDR-V1.0
DATA_SET_NAME = "MRO MARS HIGH RESOLUTION IMAGING SCIENCE
EXPERIMENT EDR V1.0"
PRODUCER_INSTITUTION_NAME = "UNIVERSITY OF ARIZONA"
PRODUCER_ID = UA
PRODUCER_FULL_NAME = "ALFRED MCEWEN"
OBSERVATION_ID = PSP_002733_1880
MRO:COMMANDED_ID = PSP_002733_1880
PRODUCT_ID = PSP_002733_1880_RED4_0
PRODUCT_VERSION_ID = 2
SOURCE_FILE_NAME = 4A_01_482AB57800_05_0_01.DAT
INSTRUMENT_HOST_NAME = "MARS RECONNAISSANCE ORBITER"
INSTRUMENT_HOST_ID = MRO
INSTRUMENT_NAME = "HIGH RESOLUTION IMAGING SCIENCE EXPERIMENT"
INSTRUMENT_ID = HIRISE
TARGET_NAME = MARS
MISSION_PHASE_NAME = "PRIMARY SCIENCE PHASE"
ORBIT_NUMBER = 2733
RATIONALE_DESC = "Faulted layers in Danielson Crater"
SOFTWARE_NAME = "HiRISE_Observation v2.10.6 (2.47 2009/06/01
05:08:10)"
FLIGHT_SOFTWARE_VERSION_ID = IE_FSW_V4
/* Science Channel Header Observation Data Component description. */
Object = SCIENCE_CHANNEL_TABLE
INTERCHANGE_FORMAT = BINARY
ROWS = 1
COLUMNS = 184
ROW_BYTES = 800
DESCRIPTION = "The Science Channel Table contains engineering fields
describing the operating state and commanding of the
HiRISE observation. For detailed information about the
contents and organization of this observation data
component, refer to the SCIENCE_CHANNEL_TABLE.FMT
file."
^STRUCTURE = SCIENCE_CHANNEL_TABLE.FMT
End_Object
/* Lookup Table Observation Data Component description. */
Object = LOOKUP_TABLE
INTERCHANGE_FORMAT = BINARY
ROWS = 16384
COLUMNS = 1
ROW_BYTES = 1
DESCRIPTION = "The Lookup Table (LUT) defines the translation of
14-bit input pixels to 8-bit output pixels. The table
has one column and 16384 rows, one for each input DN
value. The first entry of the table refers to the 8-bit
output value for the input pixel value 0."
Object = COLUMN
NAME = "Output Data Value"
DATA_TYPE = MSB_UNSIGNED_INTEGER
START_BYTE = 1
BYTES = 1
DESCRIPTION = "The rows represent the 8-bit output pixel value for each
14-bit input pixel. The first row contains the 8-bit pixel
value corresponding to the input DN value of 0. Each
subsequent row corresponds to the 8-bit output pixel of the
next input DN value."
End_Object
End_Object
...
Converting to ISIS Cube¶
Converting a HiRISE Image to an ISIS Cube with hi2isis
hi2isis
also converts the image header, prefix and suffix data to Isis
Binary Large OBject (BLOBs) and has other parameters.
SPICE¶
About SPICE
An important capability of ISIS is the ability to geometrically and photometrically characterize pixels in raw planetary instrument images. Information such as latitude, longitude, phase angle, incidence angle, emission angle, local solar time, sun azimuth, and a many other pixel characteristics can be computed.
To compute this information, the SPICE (Spacecraft and Planetary ephemeredes, Instrument C-matrix and Event kernel) kernels must first be determined for the image. These kernels maintain the spacecraft position and orientation over time as well as the target position and instrument specific operating modes.
For more info, see Spice Overview
Adding SPICE info with spiceinit
spiceinit
will add SPICE information to the ISIS cube.
All HiRISE Channels image cubes require spiceinit. Generally,
spiceinit
needs no other parameters than the filename (from=).
Camera Geometry¶
Once an ISIS Cube has been initialized with SPICE info, it can be used for camera geometry and photometry.
